380W 120cells half cut mono solar panel for energy system

This 120 cells Mono Solar Panel use A grade solar cells which is high quality. We provide flash report and embedded bar code ID for each module for complete traceability. Monocrystalline solar cells are the most popular option on the market, as well as the most efficient form of solar cell. You can get decent levels of efficiency with monocrystalline cellsin all weather conditions. ISO, CE, PV CYCLE certificates approved. 16 years experience pv panels supplier in china

120 half cut cell monocrystalline silicon module
Tempered glass on the front
100% EL inspection
12 years quality warrant
25-year linear performance guarantee

Production Specification

Electrical parameters at standard test conditions

(STC:AM=1.5, 1000W/m2, Cells Temperature 25°C）

Typical type	380W
Max power(Pmax)	380
Max power voltage(Vmp)	34.3
Max power current(Imp)	11.08
Open circuit voltage(Voc)	41.6
Short circuit current(Isc)	11.65
Module Efficiency(%)	20.86
Max system voltage	DC 1500V/DC 1000V
Maximum Series Fuse Rating	20A

Mechanical Data

Item	Specification
Dimensions	1755x1038x35mm
Weight	19.5kgs
Front Glass	3.2mm tempered glass
Output cables	4mm² Symmetrical lengths 1100mm
connectors	MC4 compatible IP68
Cell Type	Mono-Crystalline PERC Half-Cell 9BB 79.375mm x 158.75mm
Number of cells	120 cells in series
