US $0.20 - US $0.35 / watts
260W 54cells polycrystalline solar panel module for roof installation
5 Busbar Cell
5 Busbar Solar cell adopts new technology to improve the efficiency of modules, offers a better aesthetic appearance making it perfect for rooftop installation and application
High Efficiency
Polycrystalline 54-cell module achieves a power output up to 280Wp.
PID RESISTANT
Eagle modules pass the PID test, limited power degradation by the PID test is guaranteed for mass production.
Temperature Coefficient
Improved temperature coefficient decreases power loss during high temperatures.
Serve Weather Resilience Certified to withstand
Wind load(2400Pa) and snow load (5400Pa)
Product Specification
Electrical parameters at standard test conditions
(STC:AM=1.5, 1000W/m2, Cells Temperature 25℃)
Model Type | 260W |
Peak Power(Pmax) | 260 |
Max Power Voltage(Vmp) | 28.60 |
Max Power Current(Imp) | 9.10 |
Open circuit voltage(Voc) | 35.0 |
Short circuit current(ISC) | 9.46 |
Module Efficiency(%） | 17.70 |
Max system voltage | DC 1500V/DC 1000V |
Dimensions | 1480X992X35mm |
Weight | 15.60kgs |
Front glass | 3.2mm tempered glass |
Output cables | 4mm² |
Connectors | MC4 compatible IP67 |
Cell type | Poly |
Number of cells | 54 cells in series |
Our Service
1, All of our solar panels can be customized in size, voltage, power, and shape, and ensure high power and performance.
2, Our sales team 24 hours online, can reply to your mail in time.
3, Affordable, delivery on time, 15-20 days lead time for glass solar panels, and flexible solar panels always have in stock.
4, Know well about the solar energy industry, can provide specialized guidance to customers, such as the controller, inverter selection, the installation solution, and so on.
5, As long as send an order to our company, you will always be our VIP customer, we will act in updating and adjusting the product price regularly.
Welcome to inquiry our 260W polycrystalline solar panel!!
