US $0.20 - US $0.35 / watt
330W Black Mono Half Cut solar panels
This 330W mono black half cut solar panels use dark blue cells, black backsheet, black frame, make the panel full black with good appearance. can be applied in RV, Boat, Back-up power, Cabin, commercial and residential.
Product Specification:
Electrical parameters at standard test conditions
(STC:AM=1.5, 1000W/m2, Cells Temperature 25°C）
Typical Type | 330W |
Max Power(Pmax) | 330 |
Max Power voltage(Vmp) | 33.8 |
Max Power current(Imp) | 9.76 |
Open circuit voltage(Voc) | 40.6 |
Short circuit current(Isc) | 10.39 |
Module Efficiency(%） | 19.62% |
Max system voltage | DC 1500V(TUV)/DC 1000V(TUV) |
Maximum Series Fuse Rating | 16A |
Mechanical Data
| Item | Specification |
Dimensions | 1685*1002*35mm |
Weight | 18kgs |
Front glass | 3.2mm tempered glass |
Output cables | 4mm² |
Connectors | MC4 compatible IP68 |
Cell type | Mono Crystalline PERC Half-Cell |
Number of cells | 120 cells |
Packing Configuration
Item | Specification | ||
Container | 20'GP | 40'GP | 40'HQ |
Pieces per pallet | 60 | 60 | 64 |
Pallets per container | 5 | 11 | 11 |
Pieces per container | 372 | 780 | 832 |
Which fields can the photovoltaic system be used in?
(1) Remote areas, isolated islands and other areas without electricity;
(2) Highway, railway, shipping and transportation;
(3) Communication and communications;
(4) petroleum, Marine, meteorological and aerospace fields;
(5) Solar photovoltaic lighting, photovoltaic power station;
(6) Solar photovoltaic building integration system;
(7) Solar goods and toys.
What advantage of photovoltaic system?
(1) No traditional energy consumption, no toxic gas and carbon dioxide gas emissions, no hazardous waste emissions;
(2) Green electricity, clean and environmental protection;
(3) Low cost of late operation and power generation, less maintenance costs;
(4) Quiet operation, no noise;
(5) Especially suitable for remote areas, isolated islands without electricity, power shortage areas.
Technology Advantage
1.LOW LID(Silicon Wafer With Ga)
2.Synergism EVA
3.100% EL Test With 24 Megapixel HD Camera
4.Four Steps Appearance Inspect
5.MBB Cells Increase 10W
FAQ
1.Q:Could you produce 166mm cell?
A:Yes,we do.
2.Q:Do you have stock warehouse in EU market?
A:Yes, we have. We set warehouse in Rotterdam and Poland to keep regular customs clearance stock solar panels.
3.Q:May i have a piece of sample to check the quality?
A:Welcome to place the testing order to check the quality or for testing.
4.Q:How about the delivery time?
A:Generally, the order takes 15-20 days after receiving your payment.
The specific delivery time depends on the items and the order quantity.
5.Q:Where is the port of loading?
A:Ningbo or Shanghai
6.Q:Can you do OEM?
A:Yes, we are welcome to do OEM for our clients.
7.Q:Could we be your agent or distributor?
A:Yes, we do.
